Vanadium oxide uncooled focal plane arrays Thermal Sensor
2.0 Megapixel 1/2.8’’ Progressive Scan CMOS Sensor
High definition and smooth picture, 1080p@60fps (Optical)
H.265 video codec, saves up to 50% bandwidth and storage
Ultra low illumination, 0.001lux with color picture
120dB Ultra WDR
Laser automatically adjusts
HLC / 3D noise reduction
High sensitivity thermal module, 800 x 600@30fps (IPC523-F255-NR150)
Up to 9 palettes of adjustable color
Motion detection / Tampering / Guard line / Enter guard area / Exit guard area / Object left / Object removal / Gathering / Audio surge
Industrial components, withstands operation temperatures of -40°C ~ 70°C
IP66, TVS 6000V lightning protection, surge protection and voltage transient protection
55x optical zoom
SD card optional, supports Automatic Network Replenishment (ANR)
Up to 3 video streams
Bi-directional audio / alarm in and out / video out
Wiper supported
IPC523-F255-NR025 | IPC523-F255-NR050 | IPC523-F255-NR150 | |
Thermal Module | |||
Image Sensor | Vanadium Oxide Uncooled Focal Plane Arrays | ||
Resolution | 400 x 300 | 800 x 600 | |
Lens | 25mm | 50mm | |
Detector Pitch | 17μm | ||
NETD | < 40mk(@25°C,F#=1.0) | ||
Response Waveband | 8μm ~ 14μm | ||
Color mode | up to 9 modes | ||
Optical Camera | |||
Image Sensor | 1/2.8’’ Progressive Scan CMOS | ||
Pixels | 2.0 Megapixel | ||
Min. Illumination | Color: 0.001Lux @ (F1.2, AGC ON) | ||
B/W: 0.0001Lux @ (F1.2, AGC ON); 0Lux with IR | |||
Shutter Speed | 1 ~ 1/30,000S | ||
Day / Night | Auto (ICR) / Color / B/W | ||
Wide Dynamic Range | Ultra WDR, >=120dB | ||
S/N Ratio | >55dB | ||
White Balance | Auto / Manual | ||
Gain Control | Auto / Manual | ||
Backlight Compensation | Off / WDR / BLC / HLC | ||
Lens | |||
Focal Length | 6.6 ~ 363mm, 55x optical | ||
Zoom Speed | Approx 4s (Optical) | ||
Angle of View | 43.8°~ 1° (Wide~Tele) | ||
Min. Object Distance | 300 ~ 1500mm (Wide~Tele) | ||
Max. Aperture Ratio | F1.6 (Wide) / F6.0(Tele) | ||
Focus Control | Auto / Manual / Semi-Automatic | ||
Pan and Tilt | |||
Pan / Tilt Range | 360° Endless / - 85° ~ 85° (Auto Flip) | ||
Pan / Tilt Speed | Pan manual speed: 0.1° ~ 120°/s; Pan preset speed: 120°/s | ||
Tilt manual speed: 0.1° ~ 30°/s; Tilt preset speed: 100°/s | |||
Proportional Zoom | Pan / Tilt speed can be adjusted automatically according to zoom multiples | ||
Preset | 256 | ||
Patrol | 8 Patrols scheme, up to 32 presets per patrol | ||
Power-off Memory | Power-off memory / Power-on recovery | ||
Auto Guard | Path / Preset / Pan scan | ||
PT Limit | Manual / Scan / Pan | ||
3D Positioning | PTZ control with mouse click and drag | ||
Wiper | Supported | ||
Video | |||
Compression Format | H.265 / H.264 / MJPEG | ||
Image Resolution | Main stream: 1080p | ||
Secondary stream: D1 | |||
Frame Rate | Main stream: 1080p@60fps | ||
Secondary stream: D1@30fps | |||
Bitrate | 32kbps ~ 16Mbps | ||
Bitrate Control | VBR / CBR | ||
Multi stream | Supported | ||
Caption | Date and time / Alarm / Direction / Customized | ||
Privacy Masking | Up to 4 zones | ||
Motion Detection | Up to 4 zones | ||
Video Freeze | Supported | ||
ROI | Supported | ||
Digital Noise Reduction | 3D noise reduction | ||
Digital Defog | Supported | ||
Image Flip | Flip / Mirror | ||
Audio | |||
Compression | G.711a / G.711u / ADPCM / G.722 / G.722.1c / G.726 | ||
Bitrate | 32kbps ~ 64kbps | ||
Audio Function | Bi-directional audio / AEC / Mixed audio recording / Dumb / Mute | ||
Network | |||
Network Protocols | TCP/IP, UDP, HTTP, DHCP, DNS/DDNS, RTP/RTCP, RTSP, PPPoE, FTP, VSIP, UPnP, 802.1x, NAT, QoS, SMTP, IPv4, IPv6 (optional) | ||
User Interface | IPC Control (IE, Firefox, Chrome) | ||
Max. User Access | Max. 10 Users (include 2 internal) | ||
Application Programming | ONVIF (Profile S, Profile G), GB/T 28181-2011, API, CGI | ||
Automatic Network Replenishment (ANR) | Supported | ||
Alarm | |||
Alarm Triggers | Alarm input / Network disconnect / Disk full / Disk error | ||
Intelligent | Motion detection / Tampering / Guard line / Enter guard area / Exit guard area / Object left / Object removal / Gathering / Audio surge | ||
Alarm Events | Alarm report / Recording / Text overlay / Snapshot / External output / Email notice / Acoustic alarm | ||
Interfaces | |||
Ethernet | 10/100M, RJ45 interface | ||
Audio In / Out | 1 x Line in / 1 x Line out | ||
Alarm In / Out | 1 x Input / 1 x Output | ||
Video Out | 1 x BNC, 1.0V [p-p] / 75Ω | ||
Memory Slot | Built-in Micro SD card (optional), up to 128GB | ||
Environmental | |||
Operating Temperature | -40°C ~ 70°C / -40°F ~ 158°F | ||
Operating Humidity | 10% ~ 95% | ||
Protection Level | IP66, TVS 6000V lightning protection, surge protection and voltage transient protection | ||
Electrical | |||
Power | 24V AC / 3A (Power adapter included) | ||
Power Consumption | Max. 70W (Laser on) | ||
Mechanical | |||
Weight | 10kg / 22lb (Gross Weight) | ||
Dimensions | 404 × 222.6 × 243.5mm / 15.9’’ x 8.76’’ x 9.59’’ |
