IP67, adaptive to various environments
1.5 meters drop protection
KWTP protocol for 3G / 4G / Wi-Fi transmission, improve the video stream continuity under unstable network conditions
H.264 high profile video codec, saves up to 30% bandwidth and storage
13MP main camera + 8MP front camera
Optional extendable camera types (button, badge, ear-hook)
Optional DV adaptor, supports HDMI video input
Qualcomm 8 core 1.5GHz processor
High definition and smooth picture, 1080p@30fps
Supports all types of mobile network
Supports dual SIM dual standby
Android 5.0 OS, supports third party app
5.5” 1080p HD IPS screen display
Supports location function by GPS, GLONASS
| IPW200-P1HD | ||
| System | ||
| Operating System | Android 5.0 64bit OS | |
| Processor | Qualcomm 8 core 1.5GHz | |
| RAM | 2GB | |
| Video | ||
| Compression Format | H.264 | |
| Image Resolution | Main stream: 1080p | |
| Secondary stream: D1 | ||
| Frame Rate | Main stream: 1080p@30fps | |
| Secondary stream: D1@25fps | ||
| Bitrate | 64Kbps ~ 8Mbps | |
| Dual-stream | Supported | |
| Caption | Date and time / Customized | |
| Audio | ||
| Compression | G.711a / G.7221c / ADPCM / AMR | |
| Coding Rate | 12Kbps ~ 64Kbps | |
| Audio Function | Bi-directional audio / AEC / Mixed audio recording / Dumb / Mute | |
| Display | ||
| Size | 5.5” | |
| Resolution | 1920 x 1080 | |
| Technology | IPS screen, visible under the sun | |
| Touchscreen | 5 point touch, supports gloves mode | |
| Camera | ||
| Main Camera | 13MP, Auto focus, Flashlight, Snapshot | |
| Front Camera | 8MP | |
| Network | ||
| 2G | GSM: B2 / B3 / B5 / B8 CDMA: BC0 | |
| 3G | WCDMA: B1 / B2 / B5 / B8 TD-SCDMA: B34 / B39 EVDO: BC0 | |
| 4G | FDD-LTE: B1 / B3 / B7 TD-LTE: B38 / B39 / B40 / B41 | |
| Wi-Fi | 802.11 b/g/n 2.4G | |
| Bluetooth | Bluetooth 4.0 | |
| NFC | Supported | |
| Location Technology | GPS, GLONASS | |
| Storage | ||
| ROM | 16G | |
| External Memory | MicroSD (up to 128G) | |
| Interface | ||
| Shortcut Button | PTT , Alarm | |
| Audio In / Out | Built-in Mic, Built-in Speaker, 1 x 3.5mm Stereo Earjack | |
| SIM | 2 x Micro SIM slot | |
| Extension | 1 x Private extension interface | |
| USB | 1 x Micro USB2.0 | |
| Protection | ||
| Protection Level | IP67 | |
| Drop Protection | 1.5 meters drop | |
| Battery | ||
| Capacity | 4000mAh | |
| Replaceable | Supported | |
| Built-in Camera Usage Time (Hours) * | 4G (on) | Screen on: Up to 5h Screen off: Up to 8h |
| Wi-Fi (on) | Screen on: Up to 4h Screen off: Up to 7h | |
| 4G (off) / Wi-Fi (off) | Screen on: Up to 6h Screen off: Up to 10.5h | |
| External Camera (720p) Usage Time (Hours) * | 4G (on) | Screen on: Up to 2.3h Screen off: Up to 2.8h |
| Wi-Fi (on) | Screen on: Up to 2.1h Screen off: Up to 2.5h | |
| 4G (off) / Wi-Fi (off) | Screen on: Up to 2.4h Screen off: Up to 2.9h | |
| External Camera (1080p) Usage Time (Hours) * | 4G (on) | Screen on: Up to 1.1h Screen off: Up to 1.4h |
| Wi-Fi (on) | Screen on: Up to 1h Screen off: Up to 1.3h | |
| 4G (off) / Wi-Fi (off) | Screen on: Up to 1.2h Screen off: Up to 1.4h | |
| Mechanical | ||
| Weight | 237.7g / 0.524lb (including battery) | |
| Dimensions | 163 × 83.8 × 12mm / 6.42’’ x 3.3’’ x 0.47’’ | |
| Accessories | ||
| Standard | Power adapter, USB cable, Battery, Headset | |
| Optional | Additional battery, External battery module, Button / Badge camera, Ear-hook camera, DV adaptor | |
| * All battery claims depend on network configuration and many other factors, actual results will vary. | ||
