13.3” color LCD with resolution of 1920 x 1080
Supports up to 24 units of body worn camera
Supports up to 24TB storage
Wall-mount and desktop design, easy to install
Modular design, easy to upgrade system capacity
Plug and play, auto charging and data transmission
Touch screen operation
Record seaching and playback
Auto lock after device plug in
Use the password to unlock device
Priority slot for far speed data transmission
Built-in battery protection for sudden power-off / shut down
| ZCS-KDCA1 | |
| System | |
| Operating System | Windows10 |
| Processor | Intel N3710 |
| Application System | Data Docking Station Management Software |
| RAM | 4GB |
| User Management | Admin / User |
| Log Management | User login / User operation / Alarm / Update |
| Display | |
| Size | 13.3” |
| Resolution | 1920*1080 |
| Touch Screen | Supported |
| Search & Playback | |
| File Type | Video, Audio, Pic, Log |
| Search Mode | Duration filter / Tag |
| Playback Resolution | 1 x 1080p@30fp |
| Functions | Querying, Viewing, Downloading, Removing |
| Slot | |
| Default Slot | 6 Slots by default, supports 6 units of Body Worn Camera Supports up to 3 extended modules (6 slots per module) |
| Extended Module | ZCS-KDCA1-EX6: Extended module of ZCS-KDCA1-6, 6 slots per module, supports 6 units of Body Worn Cameras |
| Slot Funtions | Battery charging, Data transmission, Lock, Priority slot, Automatic upgrade, Time correction |
| Data Loading Speed | Full load: up to 4.6MB/s per slot For priority slot: up to 15MB/s |
| Alarm | |
| System Alarm Triggers | No disk / Insufficient recording space / Network disconnected |
| Alarm Events | Buzzer / Alarm text |
| Storage | |
| Max. Internal HDDs | 3 x 3.5” hard disk drawer (1 x 4TB Hard disk included) |
| Max. 24TB (up to 8TB/each) | |
| RAID | RAID 1 |
| Interfaces | |
| Ethernet | 1 x Gigabite network port, RJ45 interface |
| Audio Out | Build-in speaker |
| Point lock | 1 x Point lock (Unlock all devices at the same time bye key) |
| USB | 1 x USB 2.0: for extended device 2 x Mini USB: for thirdparty device charging 2 x Micro USB: for thirdparty device charging |
| Environmental | |
| Operating Temperature | -10°C ~ 55°C / 14°F ~ 131°F |
| Operating Humidity | 10% ~ 95% |
| Electrical | |
| Power | 100 ~ 240V AC, 50 ~ 60Hz |
| Power Consumption | ZCS-KDCA1-6: Max. 105W ZCS-KDCA1-6 + 1 x ZCS-KDCA1-EX6: Max. 135W ZCS-KDCA1-6 + 2 x ZCS-KDCA1-EX6: Max. 165W ZCS-KDCA1-6 + 3 x ZCS-KDCA1-EX6: Max. 195W |
| Power-Off Protection | Built-in battery: 2150mAh |
| Mechanical | |
| Weight | ZCS-KDCA1-6: 10.3Kg / 22.7lb (HDD not included) ZCS-KDCA1-EX6: 3.68Kg/8.11lb |
| Dimensions | ZCS-KDCA1-6: 430 x 510 x 98mm / 16.92’’ x 20.08’’ x 3.86’’ ZCS-KDCA1-EX6: 190 x 510 x 98mm / 7.48’’ x 20.08’’ x 3.86’’ |
