| Model | JY-P3-X15L (Single Power Single Receiver) | JY-P3-X12L (Single Power Single Receiver) | |
 Bitmap | Bitmap | ||
| Module | Pixel Configuration | SMD 3 in 1 | SMD 3 in 1 |
| Pixel Pitch (mm) | 1.5625 | 1.25 | |
| Module Resolution (W × H) | 96 × 108 | 120 × 135 | |
| Module Dimensions (W × H × D) | 150.00 × 168.75 x 11.68 (mm) | 150.00 × 168.75 x 11.68 (mm) | |
| Unit | No. of Modules per Unit (W × H) | 4 × 2 | 4 × 2 |
| Unit Resolution (W x H) | 384 × 216 | 480 × 270 | |
| Unit Dimensions (W × H × D) | 600 × 337.5 × 69 (mm) | 600 × 337.5 × 69 (mm) | |
| Unit Area (m2) | 0.2025 | 0.2025 | |
| Weight per Unit (kg / unit) | 6.6 | 6.6 | |
| Flatness of Unit (mm) | ≤ 0.1 | ≤ 0.1 | |
| Hardware Interface | Video Receive Port (RJ45) | 1 | 1 |
| Power Input Port | 1 | 1 | |
| Brightness Correction of Single Point | Supported | Supported | |
| Color Correction of Single Point | Supported | Supported | |
| White Balance Brightness (nits) | 800 (CT 6500k, by correction) | 800 (CT 6500k, by correction) | |
| CT (K) | 2000~9300, adjustable | 2000~9300, adjustable | |
| Viewing Angle (H) | 160° | 160° | |
| Viewing Angle (V) | 160° | 160° | |
| Central Light Deviation | ≤ 2.5% | ≤ 2.5% | |
| Brightness Uniformity | ≥ 98% | ≥ 98% | |
| Color Uniformity | Within ±0.003 Cx, Cy | Within ±0.003 Cx, Cy | |
| Contrast Ratio | 5000:1 | 5000:1 | |
| Electrical | Max. Power Consumption | 106W/unit, 524W/m2 | 135W/unit,666W/m2 |
| Avg Power Consumption | 35W/unit, 173W/m2 | 45W/unit, 222W/m2 | |
| Power Supply | AC100~240V (50~60 Hz) | AC100~240V (50~60 Hz) | |
| Processing Capacity | Driving Mode | Constant Current Drive | Constant Current Drive |
| Frame Rate (Hz) | 50 / 60 | 50 / 60 | |
| Refresh Rate (Hz) | 3840 | 3840 | |
| Operation | Lifetime (Hrs) | 100,000 | 100,000 |
| Operating Temp. (℃ ) | -10 ~ +55 | -10 ~ +55 | |
| Storage Temp. (℃ ) | -25 ~ +85 | -25 ~ +85 | |
| Operating Humidity (RH) | 10 ~ 90% RH non-condensing | 10 ~ 90% RH non-condensing | |
| Storage Humidity (RH) | 10 ~ 95% RH non-condensing | 10 ~ 95% RH non-condensing | |
| Maintenance | Serviceability | Module front maintenance | Module front maintenance |
