4.0 Megapixel 1/1.8'' progressive scan CMOS sensor
High definition and smooth picture, 2688 x 1520@30fps
H.265 video codec, saves up to 50% bandwidth and storage
3D noise reduction / Auto Iris / HLC
Motion detection / Tampering / Guard line / Defocus / Scene change / Enter guard area / Exit guard area / Object left / Object removal / Gathering / Audio surge
Up to 36 targets simultaneously
Target capturing
Bi-directional people counting
Built-in picture comparison algorithm, best picture selection
Face Intelligence Exposure
Integrated High Efficiency IR
Industrial IR LED with long operational lifespan
Up to 50m IR distance
Smart IR function
Supports 90°, 180°, 270° image rotation
Varifocal AF lens
Micro SD card slot, support Automatic Network Replenishment (ANR)
Bi-directional audio / alarm in and out / video out / RS485
2 channel audio input simultaneously
Up to 3 Multi-stream
-40°C ~ 70°C operation temperature
PoE
IP67
| IPC2451-Fi4N&Fi4NB-SIR50 | |
| Camera | |
| Image Sensor | 1/1.8’’ progressive scan CMOS |
| Pixels | 4.0 Megapixel |
| Min. Illumination | Color: 0.005lux @ (F1.2, AGC ON) |
| B/W: 0.0005lux @ (F1.2, AGC ON); 0Lux with IR | |
| Shutter Speed | 1 ~ 1/30,000s |
| Day / Night | Auto (ICR) / Color / B/W |
| Wide Dynamic Range | Digital WDR |
| S/N Ratio | >=58dB |
| White Balance | Auto / Manual |
| Gain Control | Auto / Manual |
| Backlight Compensation | Off / BLC / WDR / HLC |
| Lens | |
| Auto Iris | DC drive |
| Focal Length | -Z2812: 2.8-12mm @ F1.2 motorized varifocal AF lens -Z8032: 8-32mm @ F1.2 motorized varifocal AF lens |
| Focus Control | Manual / Semi-Automatic / Auto |
| Angle of View | -Z2812: 45.5°~ 91° -Z8032: 15°~ 38° |
| Infrared | |
| IR Distance | 50m |
| IR Intensity | Smart IR |
| Video | |
| Compression | H.265 / H.264 / MJPEG |
| Image Resolution | Main stream: 2688 x 1520 |
| Secondary stream: D1 | |
| Frame Rate | Main stream: 2688 x 1520@25fps |
| Secondary stream: D1@25fps | |
| Bitrate | 32kbps ~ 16Mbps |
| Bitrate Control | VBR / CBR |
| Multi-stream | Supported |
| Caption | Date and time / Alarm / Customized |
| Privacy Masking | Up to 4 zones |
| Motion Detection | Up to 4 zones |
| Video Freeze | Supported |
| ROI | Supported |
| Digital Noise Reduction | 3D noise reduction |
| Digital Defog | Supported |
| Image Flip | Flip / Mirror / Rotation at 90°,180°,270° |
| Audio | |
| Compression | G.711a / G.711u / ADPCM / G.722 / |
| Bitrate | 32kbps ~ 64kbps |
| Audio Function | Bi-directional audio / AEC / Mixed audio recording / Dumb / Mute |
| Network | |
| Network Protocols | TCP/IP, UDP, HTTP, DHCP, DNS/DDNS, RTP/RTCP, RTSP, PPPoE, FTP, IGMP, VSIP, UPnP, 802.1x, NAT, QoS, SMTP, IPv4, IPv6 (optional) |
| User Interface | IPC Control (IE, Firefox, Chrome) |
| Max. User Access | Max. 10 Users (includes 2 internal) |
| Application Programming | ONVIF (Profile S, Profile G), GB/T 28181-2011, API, CGI |
| Automatic Network Replenishment (ANR) | Supported |
| Recognitive Functions | |
| Target Detection | Person, Face |
| Captured Picture | Person, Face Built-in picture comparison algorithm, best picture selection |
| Target Characters | Direction / Speed level |
| People Counting | Bi-directional |
| Face Enhancement | Face Intelligence Exposure |
| Alarm | |
| Alarm Triggers | Alarm input / Network disconnect / Disk full / Disk error |
| Intelligent | Motion detection / Tampering / Guard line / Defocus / Scene change / Enter guard area / Exit guard area / Object left / Object removal / Gathering |
| Alarm Events | Alarm report / Recording / Text overlay / Snapshot / External output / Email notice / Acoustic alarm |
| Interfaces | |
| Ethernet | 10/100M, RJ45 interface |
| Audio In / Out | 2 x Line in / 1 x Line out |
| Control | 1 x RS485 |
| Alarm In / Out | 1 x Input / 1 x Output |
| Memory Slot | Micro SD card slot, supports up to 128GB |
| Environmental | |
| Operating Temperature | -40°C ~ 70°C / -40°F ~ 158°F |
| Operating Humidity | 10% ~ 95% |
| Protection level | IP67 |
| Electrical | |
| Power | DC 12V ± 10% / AC 24V ± 10% / PoE (IEEE802.3at) |
| Power Consumption | Max. 15W |
| Mechanical | |
| Weight | -FNB: 2.5kg / 5.5lb (Gross Weight) -FN: 2kg / 4.4lb (Gross Weight) |
| Dimensions | -FNB: 313.6 x 108.8 x 157mm / 12.35'' x 4.28'' x 6.19'' -FN: 233.3 x 108.8 x 91.9mm / 9.19'' x 4.28'' x 3.62'' |
| Mounting Bracket | -FNB: Bracket included -FN: Bracket not included |
