H.265 supported
4 x 4K@30fps / 16 x 1080p@30fps video decoding capability
Up to 32 channel
Up to 320Mbps incoming bandwidth
256Mbps output bandwidth
16 user access simultaneously
Max. 4 HDDs up to 32TB storage
Supports deep learning algorithm
Supports up to 6,000 face detection comparison library
Supports up to 12,000 LPR detection comparison library
Real-time multiple face and LPR matching
Supports searching picture by face picture
Auto network organizing
Built-in DHCP server
Embedded Linux
RAID 0/1/5/6/10
Supports Automatic Network Replenishment (ANR)
Supports Packet Loss Recovery (PLR)
HDMI/VGA simultaneously output different content
E-Map, TV-Wall supported
Bi-directional audio, Broadcasting
NAT
Alarm management
Free CMS (V Station), supports 128 NVR simultaneously
CMS supports 6 screens simultaneously (4 x Live viewing, 1 x E-Map, 1 x TV-Wall)
| NVR2821-04009B/2LI | NVR2821-04016B/2LI | NVR2821-04032B/2LI | |
| Video/Audio Input | |||
| IP Camera Input | 9 channel | 16 channel | 32 channel |
| Resolution | 8MP(4K), 6MP, 5MP, 4MP, 3MP, 1080p, UXGA, 960p, 720p, XGA, SVGA, D1, CIF, QCIF | ||
| Compression | H.265 / H.264 | ||
| Protocols | Onvif, RTSP, KEDACOM | ||
| Bit rate | 64kbps ~ 16384kbps | ||
| Incoming Bandwidth | 90Mbps | 160Mbps | 320Mbps |
| Live Viewing | |||
| Local Display | 1 x HDMI, 1 x VGA, simultaneously output different content | ||
| Multi Screen Display Local monitor (Main / Secondary): | 1/1, 4/4, 1+5/1+5, 1+7/1+7, 9/9 | 1/1, 4/4, 1+5/1+5, 1+7/1+7, 9/9, 16/16 | 1/1, 4/4, 1+5/1+5, 1+7/1+7, 9/9, 16/16 |
| Multi Screen Display Client | up to 4 screen simultaneously: 1 ~ 64 Multiple Layouts | ||
| E-Map | Live Viewing in E-Map (V Station) | ||
| Function | E-PTZ / Scheme (V Station) | ||
| Recording | |||
| Resolution | 8MP(4K), 6MP, 5MP, 4MP, 3MP, 1080p, UXGA, 960p, 720p, XGA, SVGA, D1, CIF, QCIF | ||
| Mode | Manual / Continuous / Schedule / Event (Pre / Post) | ||
| Event Trigger | Supported | ||
| Tag | Supported | ||
| Reliability | Automatic Network Replenishment (ANR) | ||
| Search & Playback | |||
| Search Mode | Date and time (Calendar) / Event | ||
| Resolution | 8MP(4K), 6MP, 5MP, 4MP, 3MP, 1080p, UXGA, 960p, 720p, XGA, SVGA, D1, CIF, QCIF | ||
| Playback (Local Monitor) | 4 x 4K@30fps / 16 x 1080p@30fps | ||
| Playback (Client) | up to 16 x 4K@30fps | ||
| Synchronize Playback (Local Monitor) | 4 x 4K@30fps / 16 x 1080p@30fps | ||
| Synchronize Playback (Client) | up to 16 x 4K@30fps | ||
| Function | Slow forward / Fast forward / Loop / Single frame / E-PTZ / Slice playback | ||
| Storage | |||
| Max. Internal HDDs | 4 x 3.5’’ HDD | ||
| Max. 32TB (up to 8TB/each) | |||
| RAID | RAID 0/1/5/6/10 | ||
| External | IPSAN (iSCSI), up to 10 x IPSAN, Max. 100T (optional) | ||
| Function | Disk group / Quota / Disk dormancy / Face pictures storage | ||
| Audio | |||
| Compression | G.711a / G.711u / ADPCM / G.722 / G.722.1c / G.726 | ||
| Bit rate | 32kbps ~ 64kbps | ||
| Audio Function | Bi-directional audio / Dumb / Mute / Broadcasting | ||
| Alarm | |||
| Service Alarm Triggers | Alarm input / Video lost / Motion detection / Tampering / Guard line / Defocus / Scene change / Enter guard area / Exit guard area / Object left / Object removal / Gathering / Audio surge / Face matching | ||
| System Alarm Triggers | Device disconnected / No disk / Disk error / IP Address conflict / Network disconnected / Low speed / Insufficient recording space / MAC address conflict / Insufficient Snapshot storage space | ||
| Alarm Events | Snapshot / Recording / PTZ preset / Buzzer / Email / Link to Client / Alarm caption / Live view in first window / Link to TV Wall / Link to secondary screen / Full screen viewing | ||
| AI | |||
| Face Matching | Real-time / Post-event | ||
| Search Mode | Date and time / Camera / Face image | ||
| Recognitive Camera Channel | Up to 2 | ||
| Face Recognition Access Control Terminal Channel | Up to 9 | Up to 16 | Up to 32 |
| People Counting Sensor Channel | Up to 9 | Up to 16 | Up to 32 |
| LPR Camera Channel | Up to 2 | ||
| Face picture Library | 64 libraries | ||
| Up to 1,000 (6000 face comparison library optional) | |||
| LPR Library | Up to 12,000 | ||
| System | |||
| Operating System | Embedded Linux | ||
| User Management | Admin / User | ||
| Log Management | User login / User operation / Alarm / Backup / Update | ||
| Application Programming | V Station SDK | ||
| Network | |||
| Network Protocols | TCP/IP, UDP, HTTP, DHCP, DNS/DDNS, RTP/RTCP, RTSP, PPPoE, FTP, SNTP, VSIP, UPNP, SMTP, IPv4, IPv6 (optional) | ||
| Viewer Software | CMS (V Station) / Web / iOS app / Android app | ||
| Max. User Access | 16 Users | ||
| Output Bandwidth | 256Mbps | ||
| Function | NAT / Multiple network access / Packet loss recovery / Auto network organizing | ||
| Network Test | Supported | ||
| Interfaces | |||
| Ethernet | 3 x Gigabit network port, RJ45 interface | ||
| Video Out | 1 x HDMI (up to 3840 x 2160@60Hz) | ||
| 1 x VGA (up to 1920 x 1080@60Hz) | |||
| Audio In / Out | 1 x RCA Line in / 1 x RCA Line out | ||
| Control | 1 x RS485, 1 x RS232 | ||
| USB | 2 x USB2.0, 2 x USB3.0 | ||
| Environmental | |||
| Operating Temperature | -10°C ~ 55°C / 14°F ~ 131°F | ||
| Operating Humidity | 10% ~ 85% | ||
| Electrical | |||
| Power | 100 ~ 240V AC, 50 ~ 60Hz | ||
| Power Consumption | Max. 150W (HDD not included) | ||
| Mechanical | |||
| Weight | 13kg / 28.66lb (Gross Weight) | ||
| Dimensions | 443 x 461 x 88mm / 17.44’’ x 18.15’’ x 3.46’’ | ||
