2.0 Megapixel 1/2.8’’ progressive scan CMOS sensor
High definition and smooth picture, 1080p@30fps
H.265 video codec, saves up to 50% bandwidth and storage
Ultra low illumination, 0.002lux with color picture
120dB Ultra WDR
3D noise reduction / Auto Iris / HLC
Motion detection / Tampering / Guard line / Enter guard area / Exit guard area
Industrial IR LED with long operational lifespan
15m IR distance
Smart IR function
Supports 90°, 180°, 270° image rotation
Micro SD card slot, supports Automatic Network Replenishment (ANR)
Bi-directional audio / Built-in Mic
Wi-Fi supported (-FNW only)
Dual-stream (1080p + D1)
Anti-fog glass
EN50155
PoE
IK10
IP67
| IPC2241-FN-PIR | IPC2241-FNW-PIR | |
| Camera | ||
| Image Sensor | 1/2.8’’ progressive scan CMOS | |
| Pixels | 2.0 Megapixel | |
| Min. Illumination | Color: 0.002lux @ (F2.0, AGC ON) | |
| B/W: 0.0002lux @ (F2.0, AGC ON); | ||
| Shutter Speed | 1 ~ 1/30,000s | |
| Day / Night | Auto (ICR) / Color / B/W | |
| Wide Dynamic Range | Ultra WDR, >=120dB | |
| S/N Ratio | >58dB | |
| White Balance | Auto / Manual | |
| Gain Control | Auto / Manual | |
| Backlight Compensation | Off / WDR / BLC / HLC | |
| Lens | ||
| Mount Type | M12 | |
| Focal Length | 2.8mm (-L0280) / 3.6mm (-L0360) / 6mm (-L0600) / 8mm (-L0800) | |
| Angle of View | 101.2° (-L0280) / 78.6° (-L0360) / 53.2° (-L0600) / 36.8° (-L0800) | |
| Adjustment Range | Pan: -45° ~ 45° / Tilt: 0° ~ 90° / Rotation: 0° ~ 360° | |
| Infrared | ||
| IR Distance | 15m | |
| IR Intensity | Smart IR | |
| Video | ||
| Compression | H.265 / H.264 / MJPEG | |
| Image Resolution | Main stream: 1080p | |
| Secondary stream: D1 | ||
| Frame Rate | Main stream: 1080p@30fps | |
| Secondary stream: D1@30fps | ||
| Bitrate | 32kbps ~ 8Mbps | |
| Bitrate Control | VBR / CBR | |
| Dual-stream | Supported | |
| Caption | Date and time / Alarm / Customized | |
| Privacy Masking | Up to 4 zones | |
| Motion Detection | Up to 4 zones | |
| ROI | Supported | |
| Digital Noise Reduction | 3D noise reduction | |
| Digital Defog | Supported | |
| Image Flip | Flip / Mirror / Rotation 90°, 180°, 270° | |
| Audio | ||
| Compression | ||
| Bitrate | 32kbps ~ 64kbps | |
| Audio Function | Bi-directional audio / AEC / Mixed audio recording / Dumb / Mute | |
| Network | ||
| Network Protocols | TCP/IP, UDP, HTTP, DHCP, DNS/DDNS, RTP/RTCP, RTSP, PPPoE, FTP, IGMP, VSIP, UPnP, 802.1x, NAT, QoS, SMTP, IPv4, IPv6 (optional) | |
| User Interface | IPC Control (IE, Firefox, Chrome) | |
| Max. User Access | Max. 10 Users (includes 2 internal) | |
| Wireless | / | Wi-Fi |
| Wi-Fi | / | 802.11b/g/n 2.4G, Wi-Fi AP |
| Application Programming | ONVIF (Profile S, Profile G), GB/T 28181-2011, API, CGI | |
| Automatic Network Replenishment (ANR) | Supported | |
| Alarm | ||
| Alarm Triggers | Network disconnect / Disk full / Disk error | |
| Intelligent | Motion detection / Tampering / Guard line / Enter guard area / Exit guard area | |
| Alarm Events | Alarm report / Recording / Text overlay / Snapshot / Email notice | |
| Interfaces | ||
| Ethernet | 10/100M, RJ45 interface | |
| Wi-Fi | / | Built-in Wi-Fi module |
| Audio In / Out | 1 x Built-in Mic | |
| Memory Slot | Micro SD card slot, supports up to 256GB | |
| Environmental | ||
| Operating Temperature | -40°C ~ 70°C / -40°F ~ 158°F | |
| Operating Humidity | 10% ~ 95% | |
| Protection level | IK10, IP67, EN50155 | |
| Electrical | ||
| Power | 12V DC ± 25% / PoE (IEEE802.3af) | |
| Power Consumption | Max. 8W | |
| Mechanical | ||
| Weight | 0.5 kg / 1.1lb (Gross Weight) | |
| Dimensions | Φ103.7 × 56.4mm / Φ4.08’’ x 2.22’’ | |
