2.0 Megapixel 1/2.8’’ progressive scan CMOS sensor
High definition and smooth picture, 1080p@30fps
H.265 video codec, saves up to 50% bandwidth and storage
Ultra low illumination, 0.002lux with color picture
WDR / HLC / 3D noise reduction
Driver behavior detection of fatigue driving, yawning, smoking, inattention, calling and absence
Industrial IR LED with long operational lifespan
15m IR distance
Smart IR function
Micro SD card slot, supports Automatic Network Replenishment (ANR)
Bi-directional audio / Built-in Mic / alarm in and out / RS485
Wi-Fi supported
3G / 4G supported (-GiCWG only)
Dual-stream (1080p + D1)
Anti-fog glass
EN50155
PoE
IK10
IP67
| IPC2241-GiCNW-SIR15-L0360 | IPC2241-GiCWG-SIR15-L0360 | |
| Camera | ||
| Image Sensor | 1/2.8’’ progressive scan CMOS | |
| Pixels | 2.0 Megapixel | |
| Min. Illumination | Color: 0.002lux @ (F2.0, AGC ON) | |
| B/W: 0.0002lux @ (F2.0, AGC ON); | ||
| Shutter Speed | 1 ~ 1/30,000s | |
| Day / Night | Auto (ICR) / Color / B/W | |
| Wide Dynamic Range | Ultra WDR, >=120dB | |
| S/N Ratio | >58dB | |
| White Balance | Auto / Manual | |
| Gain Control | Auto / Manual | |
| Backlight Compensation | Off / WDR / BLC / HLC | |
| Lens | ||
| Mount Type | M12 | |
| Focal Length | 3.6mm (-L0360) | |
| Angle of View | 78.6° (-L0360) | |
| Adjustment Range | Pan: -45° ~ 45° / Tilt: 0° ~ 90° / Rotation: 0° ~ 360° | |
| Infrared | ||
| IR Distance | 15m | |
| IR Intensity | Smart IR | |
| Video | ||
| Compression | Smart H.265 / H.265 / H.264 / MJPEG | |
| Image Resolution | Main stream: 1080p | |
| Secondary stream: D1 | ||
| Frame Rate | Main stream: 1080p@30fps | |
| Secondary stream: D1@30fps | ||
| Bitrate | 32kbps ~ 8Mbps | |
| Bitrate Control | VBR / CBR | |
| Dual-stream | Supported | |
| Caption | Date and time / Alarm / Customized | |
| Privacy Masking | Up to 4 zones | |
| Motion Detection | Up to 4 zones | |
| ROI | Supported | |
| Digital Noise Reduction | 3D noise reduction | |
| Image Flip | Flip / Mirror | |
| Audio | ||
| Compression | G.711a / G.711u / ADPCM / G.722 | |
| Bitrate | 32kbps ~ 64kbps | |
| Audio Function | Bi-directional audio / AEC / Mixed audio recording / Dumb / Mute | |
| Network | ||
| Network Protocols | TCP/IP, UDP, HTTP, DHCP, DNS/DDNS, RTP/RTCP, RTSP, PPPoE, FTP, VSIP, UPnP, 802.1x, NAT, QoS, SMTP, IPv4, IPv6 (optional) | |
| User Interface | IPC Control (IE, Firefox, Chrome) | |
| Max. User Access | Max. 10 Users (includes 2 internal) | |
| Wireless | Wi-Fi | |
| Wi-Fi | 802.11b/g/n 2.4G, Wi-Fi AP | |
| 3G / 4G Frequency Band | / | FDD-LTE: B1 / B3 / B5 / B8 TDD-LTE: B38 / B39 / B40 / B41 WCDMA: B1 / B8 GSM / GPRS / EDGE: 900 / 1800MHz TD-SCDMA: B34 / B39 EVDO/CDMA: BC0 |
| Application Programming | ONVIF (Profile S, Profile G), GB/T 28181-2011, API, CGI | |
| Automatic Network Replenishment (ANR) | Supported | |
| Recognitive Functions | ||
| Driver behavior detection | Fatigue driving, yawning, smoking, inattention, calling and absence | |
| Alarm | ||
| Alarm Triggers | Alarm input / Network disconnect / Disk full / Disk error | |
| Intelligent | Motion detection | |
| Alarm Events | Alarm report / Recording / Text overlay / Snapshot / External output / Email notice / Acoustic alarm | |
| Interfaces | ||
| Ethernet | 10/100M, RJ45 interface | / |
| Wi-Fi | Built-in Wi-Fi module | |
| GPS | Build-in GPS module | |
| 3G / 4G Frequency Band | Build-in 3G / 4G module | |
| Audio In / Out | 1 x Line in / 1 x Line out / 1 x Built-in Mic | |
| Control | 1 x RS485 | |
| Alarm In / Out | 2 x Input / 1 x Output | |
| Memory Slot | Micro SD card slot, supports up to 256GB | |
| Environmental | ||
| Operating Temperature | -40°C ~ 70°C / -40°F ~ 158°F | |
| Operating Humidity | 10% ~ 95% | |
| Protection level | IK10, IP67, EN50155 | |
| Electrical | ||
| Power | 12V DC ± 25% / PoE (IEEE802.3af) | |
| Power Consumption | Max. 14W | |
| Mechanical | ||
| Weight | 0.5 kg / 1.1lb (Gross Weight) | |
| Dimensions | Φ103.7 × 56.4mm / Φ4.08’’ x 2.22’’ | |
