2.0 Megapixel 1/2.8’’ Progressive Scan CMOS Sensor
High definition and smooth picture, 1080p@25fps
0.0001lux,ultra low illumination
4mm ultra wide angle dual-lens
Built-in deep learning face recognition algorithm
Support face anti-spoofing
Face intelligence exposure
Face Recogintion \ Card \ Fingerprint \ Face Recognition and Card \ Face Recognition or Card \ Face Recogintion and Fingerprint \ Face Recogintion or Fingerprint \ Face Recogintion and Card and Fingerprint \ Face Recogintion or Card or Fingerprint \ Remote Control
Support up to 20,000 face library, up to 100,000 card capacity , 50,000 fingerprint and 1,000,000 event records
8” Capacitive touchscreen
Micro SD card slot, supports Automatic Network Replenishment (ANR)
Built-in Mic and speaker / Bi-directional audio / alarm in&out / RS485 / Wiegand / exit button / lock NO NC / door contact / tamper button
-40°C ~ 60°C operation temperature
IP66 ( -FC )
KSCA121-ANW-FC | KSCA121-ANW-FMC | |
Camera | ||
Image Sensor | 2 x 1/2.8’’ Progressive Scan CMOS | |
Pixels | 2.0 Megapixel | |
Min. Illumination | Color: 0.001lux | |
Focal Length | 4mm dual-lens | |
Compression | H.264 | |
Image Resolution | 1080p@25fps | |
Bitrate | 32kbps ~ 16Mbps | |
Audio | ||
Compression | G.711a / G.711u / ADPCM / G.722 / G.726 | |
Bitrate | 32kbps ~ 64kbps | |
Audio Function | Bi-directional audio / AEC / Mixed audio recording / Dumb / Mute | |
Display | ||
Size | 8” | |
Type | LCD | |
Resolution | 800 x 1280 | |
Operation Method | Capacitive touchscreen | |
Screen Hardness | >= 6H | |
Access Control | ||
Card Reader | IC / M1 / CPU card | |
Card Capacity | 100,000 | |
Face Detection Comparison Library | 20,000, 50,000 (optional) | |
Fingerprint Capacity | / | 50000 |
Unlock Mode | Face Recogintion \ Card \ Face Recognition and Card \ Face Recognition or Card \ Remote Control | Face Recogintion \ Card \ Fingerprint \ Face Recognition and Card \ Face Recognition or Card \ Face Recogintion and Fingerprint \ Face Recogintion or Fingerprint \ Face Recogintion and Card and Fingerprint \ Face Recogintion or Card or Fingerprint \ Remote Control |
Envent Capacity | 1,000,000 | |
1:N Face Recognition | Supported | |
Face Recognition Duration (1:N) | <= 0.5s | |
Accuracy Rate | >= 99.5% | |
Face Detection Distance | 0.3 ~ 2m | |
Face Anti-Spoofing | Supported | |
Face Exposure | Supported | |
Network | ||
Network Protocols | TCP/IP, UDP, HTTP, DHCP, DNS/DDNS, RTP/RTCP, RTSP, PPPoE, FTP, VSIP, UPnP, 802.1x, NAT, QoS, SMTP, IPv4, IPv6(optional) | |
Wi-Fi | 802.11 b/g/n 2.4G | |
User Interface | IPC Control (IE, Firefox, Chrome) | |
Max. User Access | Max. 10 Users (includes 2 internal) | |
Application Programming | ONVIF (Profile S, Profile G), GB/T 28181-2011, API, CGI | |
Automatic Network Replenishment (ANR) | Supported | |
Interfaces | ||
Ethernet | 10/100M, RJ45 interface | |
Audio In / Out | 1 x Built-in Mic, 1 x Speaker | |
Control | 1 x Wiegand , 1 x RS485, 1 x Exit button, 1 x Lock NO / NC, 1 x Door contact, 1 x Tamper | |
Alarm In / Out | 2 x Input / 1 x Output | |
Memory Slot | Micro SD card slot, supports up to 256GB | |
Environmental | ||
Operating Temperature | -40°C ~ 60°C / -40°F ~ 140°F | |
Operating Humidity | 0% ~ 95%, No condensation | |
Protection Level | IP66 | / |
Electrical | ||
Power | 12V DC ± 10% | |
Power Consumption | Max. 25W | |
Mechanical | ||
Weight | 1.7kg / 3.75 lb (Gross Weight) | |
Dimensions | 215 x 94.2 x 54.2mm / 8.46’’ x 3.71’’ x 2.13’’ |
