VS-G700-A Mobile Monitoring Access to Gateway
Product Features
  • Via VS-G700-A gateway, the monitoring video of monitoring platform can be browsed with the mobile phone
  • Based on embedded structure, the system is stable and reliable
  • Support that various resolutions are transcoded to appropriate resolution of mobile phone
  • Support that the multiple-mobile browses the video at the same time and support snapshot and vide recording
  • Support the PTZ control of the camera by the mobile phone
Model
VS-G700-A
Design Structure
Embedded design
Equipment Capacity
Support mobile type
Windows_Mobile 5.0, 6.0, 6.5, support iOS4.0 and above as well as android 2.1 and above
Transcoding capacity
QVGA:32×CIF, 20×D1, 8×720P
QCIF:40×CIF, 24×D1, 10×720P
Video format
H.264
Input resolution
720P, D1, CIF, QVGA , QCIF
Output resolution
CIF, QVGA, QCIF
Typical Application
Application function
Mobile video browse, PTZ control, snapshot and video recording
Network interface
2×RJ45,100Base-TX/1000Base-T
Physical Features
Physical dimensions
19 inch 2U, 88mm (Height) ×443mm (Width) ×461mm (Depth)
Weight
13Kg
Working Environment
Power supply
Power supply AC 100~240V,50~60Hz
Power consumption
≤130W
Working temperature
0℃~55℃
Storage humidity
10%~90%RH
