Camera

Image   Sensor

1/1.8’’   progressive scan CMOS

Pixels

8.0   Megapixel

Min.   Illumination

Color:   0.0005lux @ (F1.5, AGC ON)

B/W:   0.0001lux @ (F1.5, AGC ON); 0lux with IR

Shutter   Speed

1 ~   1/30,000s

Day / Night

Auto (ICR) / Color / B/W

Wide   Dynamic Range

Ultra   WDR, >=120dB

S/N   Ratio

>=55dB

White   Balance

Auto   / Manua

Gain   Control

Auto   / Manual

Backlight   Compensation

Off   / WDR / BLC / HLC

Lens

Focal   Length

5.7   ~ 285mm, 50x optical

Zoom   Speed

Approx   4s (Optical)

Angle   of View

65.3°~   1.6° (Wide~Tele)

Min.   Object Distance

300   ~ 2000mm (Wide~Tele)

Max.   Aperture Ratio

F1.4   (Wide) / F4.2 (Tele)

Focus Control

Auto / Manual / Semi-Automatic

Laser

Laser Distance

500m

Laser   Intensity

Automatically   adjust according to zoom ratio

Pan   and Tilt

Pan   / Tilt Range

360° Endless / -20° ~ 90° (Auto Flip)

Pan   / Tilt Speed

Pan   manual speed: 0.1° ~ 240°/s; Pan preset speed: 240°/s

Tilt   manual speed: 0.1° ~ 200°/s; Tilt preset speed: 200°/s

Proportional   Zoom

Pan   / Tilt speed can be adjusted automatically according to zoom multiples

Preset

512

Patrol

8   Patrols scheme, up to 32 presets per patrol

Pattern Scan

4 Scan paths, each path can record 10   minutes of operation path

Power-off Memory

Power-off memory / Power-on recovery

Auto Guard

Path / Preset / Mixed / Pan scan / Tilt   scan / Frame scan / Random scan / Panorama scan

PT Limit

Manual / Scan / Pan

3D Positioning

PTZ control with mouse click and drag

Electronic compass

Built-in O-sensor

Auto Tracking

Supported

Video

Compression

H.265+   / H.265 / H.264 / MJPEG

Image Resolution

Main   stream: 4K (3840×2160)

Secondary   stream: D1

Frame   Rate

Main   stream: 3840 x 2160@30fps, 1080p@30fps

Secondary   stream: D1@30fps

Bitrate

256kbps   ~ 32Mbps

Bitrate   Control

VBR   / CBR

Multi-stream

Supported

Caption

Date   and time / Alarm / Direction / Customized

Privacy   Masking

Up   to 4 zones

Motion   Detection

Up   to 4 zones

Video   Freeze

Supported

ROI

Supported

Digital   Noise Reduction

3D   noise reduction

Digital   Defog / Optical Defog

Supported

Image   Flip

Flip   / Mirror

Audio

Compression

G.711a   / G.711u / ADPCM / G.722 / AAC-LC / G.722.1c / G.726

Bitrate

32kbps   ~ 64kbps

Audio   Function

Bi-directional   audio / AEC / Mixed audio recording / Dumb / Mute

Network

Network   Protocols

TCP/IP,   UDP, HTTP, DHCP, DNS/DDNS, RTP/RTCP, RTSP, PPPoE, FTP, VSIP, UPnP, 802.1x,   NAT, QoS, SMTP, IPv4, IPv6 (optional)

User   Interface

IPC   Control (IE, Firefox, Chrome)

Max.   User Access

Max.   20 Users (includes 2 internal)

Application   Programming

ONVIF   (Profile S, Profile G), GB/T 28181-2011, API, CGI

Automatic   Network Replenishment (ANR)

Supported

Recognitive   Functions

Target   Detection

Face

Captured   Picture

Face

Alarm

Alarm   Triggers

Alarm   input / Network disconnect / Disk full / Disk error

Intelligent

Motion   detection / Tampering / Guard line / Enter guard area / Exit guard area /   Object left / Object removal / Gathering / Audio surge

Alarm   Events

Alarm   report / Recording / Text overlay / Snapshot / External output / Email notice   / Acoustic alarm

Interfaces

Ethernet

10/100M,   RJ45 interface, 1 x FC

Audio   In / Out

1 x   Line in / 1 x Line out

Control

1 x   RS485

Alarm   In / Out

8 x   Input / 2 x Output

Memory   Slot

2 x   SD card slot, supports up to 256GB / slot

Environmental

Operating   Temperature

-40°C   ~ 70°C / -40°F ~ 158°F

Operating   Humidity

10%   ~ 95%

Protection   Level

IP67,   TVS 6000V lightning protection, surge protection and voltage transient   protection

Electrical

Power

24V   AC / 3A (Power adapter included), Hi PoE

Power   Consumption

Max.   50W (Laser on)

Mechanical

Weight

18   kg / 39.7lb (Gross Weight)

Dimensions

Ф290   × 529mm / Ф11.42'' x 20.83''
