Camera

Image   Sensor

1/1.8"   CMOS

Min.   Illumination

Colour:0.0005   lux (F1.6, AGC ON)

B/W:0.0001   lux (F1.6, AGC ON); 0lux with IR

Day   / Night

IR   cut filter with auto switch (ICR)

Shutter

Auto/Manual, 1 ~ 1/30,000s

WDR

150dB

S/N

>56dB

Lens

Focal   Length

2.8~18   mm

Optical   Zoom

6X

Iris

F1.5(Wide)~F2.5(Tele)

Iris   Type

P   iris

Angle   of View

H:   110.9°~ 35.1° V: 57.4°~19.6° D: 136.6°~ 40.9°

Illuminator

Illumination Distance (IR)

80 m   (262.4 ft)

IR   On/Off Control

Auto/Manual

Wavelength

850   nm

Video

Streams

Main stream: 8MP(3840*2160)

Second: 2MP(1920*1080)

Third: 2MP(1920*1080)

Fouth: 2MP(1920*1080) Fifth: D1(704*576)

Max   Frame Rate

8MP(3840*2160),   Max 50fps

Frame   Rate Recommendation

3840*216@30fps+1080P@30fps+D1@30fps

Video   Compression

Smart265;   H.265; H.264; MJPEG

Video Bit Rate

32 Kbps ~ 16 Mbps

ROI

Support

Privacy Mask

Up to 4 areas

OSD

Up to 9 OSDs


EIS

Support，EIS with Gyroscope

White   Balance

Support

Digital   Noise Reduction

2D/3D   DNR

Smart   IR

Support

Defog

Digital   Defog

Flip

Flip   / Mirror / Rotation 90°, 180°, 270°

HLC   / BLC

Support   / Fixed BLC

Recognitive   Functions

Target   Detection

Person,   Face, Vehicle, Up to 100 human simultaneously

Human   Captured Picture

Person,   Face, Built-in picture comparison algorithm, best picture selection

Human   Recognition

Human   silhouette attributes: gender, top/bottom type and color, bag, hat and   umbrella, etc.

Face   attributes: gender, age, expressions, glasses, face mask and beard, etc.

Face   Comparison

Support   face comparison,up to 100,000 face database

People   Counting

Support   bi-directional people counting

Face   Enhancement

Face   Intelligence Exposure

Vehicle   Captured Picture

Vehicle   body

Vehicle   Recognition

License   plate, color, type and etc

License   Comparison

Support   LPR comparison, up to 100,000 license plate database

Alarm

Alarm   Triggers

Alarm   input / Network disconnect / Disk full / Disk error

Basic   Intelligent

Tampering   / Defocus / Scene change / Object left / Object removal / Audio surge

Deep   Learning Intelligent

Human   & Vehicle Detection: Motion detection / Guard line / Enter guard area /   Exit guard area / People Gathering

Alarm   Events

Alarm   report / Recording / Text overlay / Snapshot / External output / Email notice   / Acoustic alarm

Audio

Audio   Compression

G.711a   / G.711u / ADPCM / G.722

Audio   Bitrate

32kbps   ~ 64kbps

Audio   Function

Bi-directional   audio / AEC / Mixed audio recording / Dumb / Mute

Storage

Edge   Storage

Micro   SD, up to 1 TB

Network   Storage

ANR

Network

Protocols

TCP/IP,   UDP, HTTP, DHCP, DDNS, RTP/RTCP, RTSP, PPPoE, FTP, UPnP, NAT, SMTP, RTMP,   IPv4, IPv6

Compatible   Integration

ONVIF   (Profile S, Profile G, Profile T); API;CGI;SDK

User/Host

Max.   25 Users

Client

IPCSearch;vClientPro;vPlayer

Interfaces

Audio   I/O

1/1

Alarm   I/O

3/2

Serial   Port

1   channel RS485 interface

Built-in   Mic

Support,   built in mic*1

Built-in   Speaker

Support

Port

12   VDC power output (for connect external mic)

Network

1 *   RJ45 10M/100M/1000M Base TX Ethernet

Optical   port

1 x   FC 10M/100M/1000M

Certification

Protection

IP67，IK10

Interfaces

Power

DC12V(±25%)   , PoE+ (IEEE 802.3at)

Power   Consumption

16W

Power   Interface

Ø   5.5 mm coaxial power plug

Dimensions

369mm(L)*124mm(W)*128mm(H)

Weight

2.5kg

Working   Environment

50 ℃   ~ 60 ℃ ( 58 °F ~ 140 °F), Humidity: ≤95% RH (non condensing)

Surge   Protection

6KV

Reset   Button

Support

Heater

Support

Junction   box

Support
