4.0 Megapixel 1/1.8’’ progressive scan CMOS sensor
High definition and smooth picture, 1920 x 1080@30fps
H.265 video codec, saves up to 50% bandwidth and storage
Ultra low illumination, 0.001lux with color picture
IR automatically adjusts
3D noise reduction / HLC / BLC
Motion detection / Tampering / Guard line / Enter guard area / Exit guard area / Object left / Object removal / Gathering / Audio surge
Industrial components, withstands operation temperatures of -40°C ~70°C
IP66, TVS 6000V lightning protection, surge protection and voltage transient protection
Target capturing
Bi-directional people counting
Built-in picture comparison algorithm, best picture selection
Micro SD card , supports Automatic Network Replenishment (ANR)
Up to 3 Multi-stream
Bi-directional audio / alarm in and out
Built-in O-sensor
PoE
IP66
| IPC442-i405-NP | |
| Camera | |
| Image Sensor | 1/1.8’’ progressive scan CMOS |
| Pixels | 4.0 Megapixel |
| Min. Illumination | Color: 0.0002Lux @ (F1.5, AGC ON) |
| B/W: 0.0001lux @ (F1.5, AGC ON); 0lux with IR | |
| Shutter Speed | 1 ~ 1/30,000s |
| Day / Night | Auto (ICR) / Color / B/W |
| Wide Dynamic Range | Digital WDR |
| S/N Ratio | >58dB |
| White Balance | Auto / Manual |
| Gain Control | Auto / Manual |
| Backlight Compensation | Off / WDR / BLC / HLC |
| Lens | |
| Focal Length | 2.7 ~ 13.5mm, 5x optical, 16x digital |
| Zoom Speed | Approx 3s (Optical) |
| Angle of View | 108.1°~ 46.6° (Wide~Tele) |
| Min. Object Distance | 10 ~ 1500mm (Wide~Tele) |
| Max. Aperture Ratio | F1.5 ~ F2.7 |
| Focus Control | Auto / Manual / Semi-Automatic |
| Infrared | |
| IR Distance | 30m |
| IR Intensity | Automatically adjust according to zoom ratio |
| Pan and Tilt | |
| Pan / Tilt Range | 360° Endless / 0° ~ 90° (Auto Flip) |
| Pan / Tilt Speed | Pan manual speed: 0.1˚~180˚/s |
| Tilt manual speed: 0.1˚~120˚/s | |
| Preset | 512 |
| Patrol | 8 Patrols scheme, up to 32 presets per patrol |
| Power-off Memory | Power-off memory / Power-on recovery |
| Auto Guard | Path / Preset / Mixed / Pan scan / Tilt scan / Frame scan / Random scan / Panorama scan |
| PT Limit | Manual / Scan / Pan |
| 3D Positioning | PTZ control with mouse click and drag |
| Electronic compass | Built-in O-sensor |
| Video | |
| Compression | H.265 / H.264 |
| Image Resolution | Main stream: 1080p |
| Secondary stream: D1 | |
| Frame Rate | Main stream: 1080p@25fps |
| Secondary stream: D1@25fps | |
| Bitrate | 32~16384Kbps |
| Bitrate Control | VBR / CBR |
| Multi-stream | Supported |
| Caption | Date and time / Alarm / Direction / Customized |
| Privacy Masking | Up to 4 zones |
| Motion Detection | Up to 4 zones |
| Video Freeze | Supported |
| ROI | Supported |
| Digital Noise Reduction | 3D noise reduction |
| Electronic Defog | Supported |
| Image Flip | Flip / Mirror |
| Audio | |
| Compression | G.711a / G.711u / ADPCM / G.722 / G.722.1c / G.726 |
| Bitrate | 32kbps ~ 64kbps |
| Audio Function | Bi-directional audio / AEC / Mixed audio recording / Dumb / Mute |
| Network | |
| Network Protocols | TCP/IP, UDP, HTTP, DHCP, DNS/DDNS, RTP/RTCP, RTSP, PPPoE, FTP, VSIP, UPnP, 802.1x, NAT, QoS, SMTP, IPv4, IPv6 (optional) |
| User Interface | IPC Control (IE, Firefox, Chrome) |
| Max. User Access | Max. 10 Users (includes 2 internal) |
| Application Programming | ONVIF (Profile S, Profile G), GB/T 28181-2011, API, CGI |
| Automatic Network Replenishment (ANR) | Supported |
| Recognitive Functions | |
| Target Detection | Person, Face |
| Captured Picture | Person, Face Built-in picture comparison algorithm, best picture selection |
| Target Tracking | Support to tracking by face |
| People Counting | Bi-directional |
| Alarm | |
| Alarm Triggers | Alarm input / Network disconnect / Disk full / Disk error |
| Intelligent | Motion detection / Tampering / Guard line / Enter guard area / Exit guard area / Object left / Object removal / Gathering / Audio surge |
| Alarm Events | Alarm report / Recording / Text overlay / Snapshot / External output / Email notice / Acoustic alarm |
| Interfaces | |
| Ethernet | 10/100M, RJ45 interface |
| Control | 1 x RS485 |
| Audio In / Out | 1 x Line in / 1 x Line out |
| Alarm In / Out | 2 x Input / 1 x Output |
| Video Out | 1 x BNC, 1.0V [p-p] / 75Ω |
| Memory Slot | SD card, supports up to 256GB |
| Environmental | |
| Operating Temperature | -40°C ~ 70°C / -40°F ~ 158°F |
| Operating Humidity | 10% ~ 95% |
| Protection Level | IP66, TVS 6000V lightning protection, surge protection and voltage transient protection |
| Electrical | |
| Power | 12V DC ± 10% (Power Adapter Not Included) / PoE (802.3at) |
| Power Consumption | Max. 30W (IR on) |
| Mechanical | |
| Weight | 2 kg / 4.4lb (Gross Weight) |
| Dimensions | Φ197 × 142mm / Φ7.76" × 5.59" |
