2.0 Megapixel 1/1.8’’ progressive scan CMOS sensor
High definition and smooth picture, 1920 x 1080@30fps
H.265 video codec, saves up to 50% bandwidth and storage
Ultra low illumination, 0.001lux with color picture
IR automatically adjusts
WDR / 3D noise reduction / HLC / BLC
Motion detection / Tampering / Guard line / Enter guard area / Exit guard area / Object left / Object removal / Gathering / Audio surge
Industrial components, withstands operation temperatures of -40°C ~70°C
IP67, TVS 6000V lightning protection, surge protection and voltage transient protection
12x optical zoom (-F112)
5x optical zoom (-F105)
IR distance up to 50m
Micro SD card optional, supports Automatic Network Replenishment (ANR)
Up to 3 Multi-stream
Bi-directional audio / alarm in and out
Built-in O-sensor
PoE (-F105-NP / -F112-NP)
IK10
IP67
| IPC422-F105-N | IPC422-F105-NP | IPC422-F112-N | IPC422-F112-NP | |
| Camera | ||||
| Image Sensor | 1/1.8’’ progressive scan CMOS | |||
| Pixels | 2.0 Megapixel | |||
| Min. Illumination | Color: 0.001lux @ (F1.6, AGC ON) | |||
| B/W: 0.0001lux @ (F1.6, AGC ON); 0lux with IR | ||||
| Shutter Speed | 1 ~ 1/30,000s | |||
| Day / Night | Auto (ICR) / Color / B/W | |||
| Wide Dynamic Range | Ultra WDR, >=120dB | |||
| S/N Ratio | >57dB | |||
| White Balance | Auto / Manual | |||
| Gain Control | Auto / Manual | |||
| Backlight Compensation | Off / WDR / BLC / HLC | |||
| Lens | ||||
| Focal Length | 2.7 ~ 13.5mm, 5x optical | 5.3 ~ 63.6mm, 12x optical | ||
| Zoom Speed | Approx 3s (Optical) | |||
| Angle of View | 113.06°~ 30.61° (Wide~Tele) | 58.2°~ 4.83° (Wide~Tele) | ||
| Min. Object Distance | 10 ~ 1500mm (Wide~Tele) | |||
| Max. Aperture Ratio | F1.6 ~ F2.8 | |||
| Focus Control | Auto / Manual / Semi-Automatic | |||
| Infrared | ||||
| IR LED | 4 pcs IR LED Array | |||
| IR Distance | 30m | 50m | ||
| IR Intensity | Automatically adjust according to zoom ratio | |||
| Pan and Tilt | ||||
| Pan / Tilt Range | 360° Endless / -15° ~ 90° (Auto Flip) | |||
| Pan / Tilt Speed | Pan manual speed: 0.1˚~220˚/s; Pan preset speed:220°/s | |||
| Tilt manual speed: 0.1˚~160˚/s ; Tilt preset speed: 160°/s | ||||
| Proportional Zoom | Pan / Tilt speed can be adjusted automatically according to zoom multiples | |||
| Preset | 256 | |||
| Patrol | 8 Patrols scheme, up to 32 presets per patrol | |||
| Pattern Scan | 4 Scan paths, each path can record 10 minutes of operation path | |||
| Power-off Memory | Power-off memory / Power-on recovery | |||
| Auto Guard | Path / Preset / Mixed / Pan scan / Tilt scan / Frame scan / Random scan / Panorama scan | |||
| PT Limit | Manual / Scan / Pan | |||
| 3D Positioning | PTZ control with mouse click and drag | |||
| Electronic compass | Built-in O-sensor | |||
| Video | ||||
| Compression | H.265 / H.264 / MJPEG | |||
| Image Resolution | Main stream: 1080p | |||
| Secondary stream: D1 | ||||
| Frame Rate | Main stream: 1080p@30fps | |||
| Secondary stream: D1@30fps | ||||
| Bitrate | 32~16384Kbps | |||
| Bitrate Control | VBR / CBR | |||
| Multi-stream | Supported | |||
| Caption | Date and time / Alarm / Direction / Customized | |||
| Privacy Masking | Up to 4 zones | |||
| Motion Detection | Up to 4 zones | |||
| Video Freeze | Supported | |||
| ROI | Supported | |||
| Digital Noise Reduction | 3D noise reduction | |||
| Electronic Defog | Supported | |||
| Image Flip | Flip / Mirror | |||
| Audio | ||||
| Compression | G.711a / G.711u / ADPCM / G.722 / G.722.1c / G.726 | |||
| Bitrate | 32kbps ~ 64kbps | |||
| Audio Function | Bi-directional audio / AEC / Mixed audio recording / Dumb / Mute | |||
| Network | ||||
| Network Protocols | TCP/IP, UDP, HTTP, DHCP, DNS/DDNS, RTP/RTCP, RTSP, PPPoE, FTP, VSIP, UPnP, 802.1x, NAT, QoS, SMTP, IPv4, IPv6 (optional) | |||
| User Interface | IPC Control (IE, Firefox, Chrome) | |||
| Max. User Access | Max. 10 Users (includes 2 internal) | |||
| Application Programming | ONVIF (Profile S, Profile G), GB/T 28181-2011, API, CGI | |||
| Automatic Network Replenishment (ANR) | Supported | |||
| Alarm | ||||
| Alarm Triggers | Alarm input / Network disconnect / Disk full / Disk error | |||
| Intelligent | Motion detection / Tampering / Guard line / Enter guard area / Exit guard area / Object left / Object removal / Gathering / Audio surge | |||
| Alarm Events | Alarm report / Recording / Text overlay / Snapshot / External output / Email notice / Acoustic alarm | |||
| Interfaces | ||||
| Ethernet | 10/100M, RJ45 interface | |||
| Audio In / Out | 1 x Line in / 1 x Line out | |||
| Alarm In / Out | 1 x Input / 1 x Output | |||
| Video Out | 1 x BNC, 1.0V [p-p] / 75Ω | |||
| Memory Slot | Built-in SD card (optional), supports up to 256GB | |||
| Environmental | ||||
| Operating Temperature | -40°C ~ 70°C / -40°F ~ 158°F | |||
| Operating Humidity | 10% ~ 95% | |||
| Protection Level | IK10, IP67, TVS 6000V lightning protection, surge protection and voltage transient protection | |||
| Electrical | ||||
| Power | 12V DC ± 25% (Power Adapter Not Included) | 12V DC ± 25% / PoE (IEEE802.3af) | 12V DC ± 25% (Power Adapter Not Included) | 12V DC ± 25% / PoE (IEEE802.3af) |
| Power Consumption | Max. 30W (IR on) | |||
| Mechanical | ||||
| Weight | 2 kg / 4.4lb (Gross Weight) | |||
| Dimensions | Φ197 × 142mm / Φ7.76" × 5.59" | |||
